| CPU Socket Type |
LGA 1700 |
| Core Name |
Raptor Lake |
| # of Cores |
24-Core (8P+16E) |
| # of Threads |
32-Threads |
| Operating Frequency |
Performance-core Base Frequency: 3.2 GHz
Efficient-core Base Frequency: 2.4 GHz |
| Max Turbo Frequency |
Intel Thermal Velocity Boost Frequency: Up to 6.0 GHz
Intel Turbo Boost Max Technology 3.0 Frequency: Up to 5.8 GHz
P-core Max Turbo Frequency: Up to 5.6 GHz
E-core Max Turbo Frequency: Up to 4.4 GHz |
| L2 Cache |
32MB |
| L3 Cache |
36MB |
| Manufacturing Tech |
Intel 7 |
| 64-Bit Support |
Yes |
| Hyper-Threading Support |
Yes |
| Memory Types |
DDR4 3200 / DDR5 5600 |
| Memory Channel |
2 |
| Max Memory Size |
192 GB |
| ECC Memory |
Supported |
| Max Memory Bandwidth |
89.6 GB/s |
| Virtualization Technology Support |
Yes |
| Integrated Graphics |
Intel UHD Graphics 770 |
| Graphics Base Frequency |
300 MHz |
| Graphics Max Dynamic Frequency |
1.65 GHz |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 / 4.0 |
| PCI Express Configurations |
Up to 1x16+4, 2x8+4 |
| Max Number of PCI Express Lanes |
20 |
| Thermal Design Power |
125W |
| Max Turbo Power |
253W |
| Cooling Device |
Cooling device not included - Processor Only |
| Compatible Desktop Chipsets |
Intel H610 / Intel H670 / Intel B660 / Intel Q670 / Intel W680 / Intel Z690 / Intel H770 / Intel B760 / Intel Z790
* BIOS update may be required when used with some old chipset motherboard |
| Operating System Supported |
Linux / Windows 10 (22H2, 21H2) / Windows 11 (22H2, 21H2) |
| Advanced Technologies |
Intel Gaussian & Neural Accelerator: 3.0
Intel Thread Director
Intel Deep Learning Boost (Intel DL Boost) on CPU
Intel Speed Shift Technology
Intel Adaptive Boost Technology
Intel Thermal Velocity Boost
Intel Turbo Boost Max Technology 3.0
Intel Turbo Boost Technology: 2.0
Intel Hyper-Threading Technology
Intel 64
Instruction Set: 64-bit
Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Enhanced Intel SpeedStep Technology
Thermal Monitoring Technologies
Intel Volume Management Device (VMD) |
| Security & Reliability |
Intel Standard Manageability (ISM)
Intel Control-Flow Enforcement Technology
Intel AES New Instructions
Secure Key
Intel OS Guard
Execute Disable Bit
Intel Boot Guard
Mode-based Execute Control (MBEC)
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT) |
